4pcs Soft Close Glass Door Hinge | Hydraulic | 8ft | 330 lbs | 5/16”-1/2” Thick | SS304 | K51GM-B4

A soft close glass door hinge uses hydraulic damping to control the final closing speed while maintaining a consistent self-closing action.

With built-in tension and speed settings, these glass door soft close hinges offer a clean panel-mounted closer solution. 3 years warranty

TALK TO SALES FIRST - NON REFUNDABLE

• DESCRIPTION
• DETAILS
• SPECIFICATIONS
• VIDEO

• Applications

  • Office & Commercial Door

  • Soft Closing

  • Speed Control
  • Interior & Exterior
  • In Swing Function
  • Non Handed Design
  • Easy Installation
  • Heavy Duty

  Product Description and Features

  • Fully adjustable closing force and speed according to environment needs
  • Numerical adjustment panel on hinge end to set up precise tension
  • Mechanical only mechanism supporting heavy duty and fully exterior
  • Aesthetically pleasing compared to floor closers for glass doors
  • UL certified cycle testing ensures many years of low maintenance.

• Installation Kits

  • Both machined #12-24 UNC ½”L and wooden tapping #12 x 1 ¼” screws included -- eight (8) of each type per hinge. Pack contains five (5) spares as well.
  • Three steel adhesive shims for gap adjustment between door and frame as needed
  • Tension Crook: Keeps hinge open during installation
  • 5mm & 3mm hex allen wrenches

  Compliance Standards

  • ANSI A156.17 Grade 1 : one million cycle testing
  • ANSI A156.7 Template Hinge : 4 ½ x 4 ½
  • CSI Spec 08 7100 Door Hardware & 08 7808 Self-closing Hinges
  • ADA Force : opening force no more than 5 lbs
  • ADA Closing Speed: at least 5 sec to move from m 90° to 12°
  • ADA Vertical Clearance: Does not intrude into the doorway as do some overhead closers

• Specifications

  Product SKU	K51GM-B4
  Hinge Type	Glass to Glass
  Hinge Material	Stainless Steel
  Door Weight	From 40lbs to 330lbs
  Approx Door Size	1150mm W x 2438mm H (4ft x 8ft)
  Door Thickness	5/16″-1/2″ (8-12.7 mm)
  Self-closing	o
  Fluid Motion	o
  Hold-open	x
  Fixing Method	Screw-On, only spot weld AFTER speed adjustment
  Color/Finish	Satin Brushed,Black
  Combination/Quantity	DS.HA.SA.SA, 4 Pack
